GEMINI HEAVY DUTY POWER WHEELCHAIR BY MERITS HEALTH Gemini Heavy-Duty Power Wheelchair by Merits Health features 4-inch ground clearance and a smart LiNX controller for reliable indoor-outdoor mobility and easy diagnostics.
GEMINI HEAVY DUTY REAR-WHEEL DRIVE POWER WHEELCHAIR PRODUCT FEATURES
HEAVY-DUTY 450 LB WEIGHT CAPACITY
Built to support up to 450 lbs while maintaining stability, comfort, and everyday performance
Built to support up to 450 lbs while maintaining stability, comfort, and everyday performance
OPTIONAL POWER ELEVATING SEAT
One of the few heavy-duty power wheelchairs offering an elevating seat, raising from 24" to 29" for greater reach and independence
One of the few heavy-duty power wheelchairs offering an elevating seat, raising from 24" to 29" for greater reach and independence
EXCEPTIONAL MANEUVERABILITY
Tight 21-inch turning radius makes it easy to navigate small indoor spaces and tight corners
Tight 21-inch turning radius makes it easy to navigate small indoor spaces and tight corners
ALL-TERRAIN PERFORMANCE
4-inch ground clearance, 10° incline rating, 14-inch foam-filled drive tires, and suspension system handle uneven surfaces with ease
4-inch ground clearance, 10° incline rating, 14-inch foam-filled drive tires, and suspension system handle uneven surfaces with ease
LONG-RANGE, RELIABLE POWER
Travel up to 20 miles per charge with a top speed of 5 mph, ideal for daily use and longer outings
Travel up to 20 miles per charge with a top speed of 5 mph, ideal for daily use and longer outings
HIGHLY CUSTOMIZABLE COMFORT
Programmable controller, reclining and adjustable seating, swivel seat base, adjustable armrests, headrest, and footplate for a personalized fit
Programmable controller, reclining and adjustable seating, swivel seat base, adjustable armrests, headrest, and footplate for a personalized fit
MERITS HEALTH GEMINI HEAVY-DUTY POWERCHAIR PRODUCT SPECIFICATION
Technical Specifications
- Max Speed: 5mph
- Range: up to 20 miles
- Turning Radius: 21″
- Ground Clearance: 4″
- Motor: DC 24V, 240W
- Battery: 12V/22NF (50AH) x 2pcs
- Charger: 5A off-board
- Gradient: 12°
- Casters: 9″ foam filled tires
- Drive Wheels: 14″ foam filled tires
- Brakes: intelligent, regenerative, electromagnetic
Dimensions
- Seat Width: 20″/22″
- Seat Depth: 20″/22″
- Seat Height: 24″-29″/22″-24″
- Backrest Height: 20″/22″
- Overall Length: 41″
- Overall Height: 45″
- Overall Width: 27″
- Total Weight: 350 lbs / 242 lbs
- Weight Capacity: 350 lbs / 450 lbs
Optional Accessories
- Elevating Legrest
- Oxygen Tank Holder
- Cane & Crutch Holder
- Walker Holder
- Foldable rear basket
- 5″ power seat lift
- Swing away joystick
- XL footplate
GEMINI POWER CHAIR MEASURING GUIDE
| Seat Depth1 Measure from the most posterior point of the body to the inside of the knee, minus at least two inches. Some prefer more leg overhang to make room for their hand when lifting their leg. Back Height2 Measured from the seat base to the top of the chair back. Power wheelchair riders need upper back support, particularly for the moment of initial acceleration. Hanger Angle3 Determines how far the toes extend away from the body, measured from the horizontal. A tighter angle allows the electric power wheelchair to turn around in less space. Depends in part on ability of the knee to bend towards the perpendicular. Seat Width4 Determined by the widest point of the body from knee to hip, plus an inch to ensure room to move. Consider bulk of clothing, particularly a heavy winter coat, if relevant. Front Seat to Floor5 Measure the leg from the back of the knee to the sole of the foot. Then subtract the thickness of the cushion when it is compressed. Next, add a minimum of two inches for footrest clearance. Electric power wheelchairs are almost never foot-propelled by the user - so excluding the additional two inch footrest height for propelling is very rare. |
GEMINI HEAVY-DUTY POWER WHEELCHAIR DOWNLOADS
GEMINI HEAVY-DUTY POWER WHEELCHAIR BROCHURE GEMINI HEAVY-DUTY POWER WHEELCHAIR USER MANUAL
GEMINI HEAVY-DUTY POWER WHEELCHAIR ORDER FORM
